TOYOTA HIGHLANDER / KLUGER HYBRID (2020+) ONLINE SERVICE WORKSHOP MANUAL SUPPLIED AS DOWNLOADABLE LINK.
This is the same service manual your local TOYOTA dealer will use when doing a repair. This manual has detailed illustrations as well as step by step instructions. Pages are printable, so run off what you need and take it with you into the garage or workshop.
ENGINE FEATURED IN THIS MANUAL: 2.5L A25A-FXS I4; 3.5L 2GR-FKS V6
REFERENCE POWERTRAIN
Engine
Gasoline:
2.0 L S20A-FTS turbo I4 (2022–present)
2.4 L T24A-FTS turbo I4 (2022–present)
2.5 L A25C-FKS I4 (China)
2.5 L A25G-FKS I4 (Crown Kluger)
3.5 L 2GR-FKS V6 (2020–2022)
Gasoline hybrid
2.5 L A25A-FXS I4
2.5 L A25D-FXS I4 (China)
2.5 L A25H-FXS I4 (Crown Kluger)
Electric motor2x Permanent Magnet Synchronous
Motors 5NM + 40 kW (54 hp; 54 PS) 4NM(hybrid)
Power output
218–220 kW (292–295 hp; 296–299 PS) (3.5 L)
197.5 kW (265 hp; 269 PS) (2.4 L turbo)
179–184 kW (240–247 hp; 243–250 PS) (2.5 L hybrid, total system output)
Transmission
8-speed UA80F "Direct Shift" ECTi automatic
eCVT with sequential shift mode (hybrid)
Hybrid drivetrainPower-split (hybrid)Battery1.6 kW·h Ni-MH (hybrid)
